Simple Displays
Overview
Reliable, High-Quality Display Panels for Host-Driven Systems
Amulet’s Simple Displays are reliable, high-quality flat-panel displays (IPS-TFT) designed for applications in which the host processor handles all graphics processing. Unlike our Interactive Digital Display Modules, these panels are “target” devices that lack the computing power and memory to generate or retain an image on their own. They rely entirely on your application processor to provide the frame buffer and manage the constant 60 Hz refresh rate. They are the ideal, cost-effective choice for engineers who already have the onboard computing power, graphical operating system, and high-bandwidth digital video interfaces (LVDS, MIPI, or 24-bit RGB-TTL) required to drive a display directly.
Challenges
Integrating a simple display panel requires specific hardware and software resources from your main system:
Host Resource Consumption
Driving a display panel requires significant CPU cycles, RAM, and FLASH memory to refresh the image at 60 Hz.
Interface Complexity
Designers must manage high-bandwidth interfaces such as LVDS, MIPI, or 24-bit RGB-TTL, which require careful PCB routing and signal-integrity management.
No Independent Touch Processing
On a Simple Display, any touch panel is merely a physical attachment. The host must manage all touch-coordinate interrupts and processing, as there is no electrical connection to the display itself for processing.
Driver Development
Engineers must write or integrate custom low-level display drivers to communicate between the host and the panel.
Longevity Concerns
Sourcing panels that won’t go EOL (End of Life) in the middle of a product’s lifecycle is a major risk for industrial and medical manufacturers.
Solutions
Amulet Simple Displays provide the reliable hardware foundation for your host-driven UI:
01
Cost-Effective Integration
Perfect for high-volume applications where the host processor already has the dedicated software, overhead, and specialized hardware to manage graphics and touch.
02
Industrial-Grade Reliability
Our panels are engineered for durability, offering high contrast, wide viewing angles, and long-term availability.
03
Flexible Touch Options
Available with integrated resistive or capacitive touch overlays to suit your specific environmental requirements.
04
Streamlined Hardware Sourcing
Avoid the headache of sourcing “consumer-grade” panels. Amulet provides production-ready displays designed for long-term stability and ease of procurement.
05
Consistent Quality
Get the same high-quality glass and touch performance found in our Interactive line, but in a standard, panel-only configuration.
AM043NDG01
4.3 Inch TFT Display
Features:
- IPS TFT
- 480 x 272 pixels
- Sunlight readable
- All viewing angle
- 24-bit RGB interface
- 3.3V LCD
Controller/Driver:
SC7283
Documentation:
Purchase
Please contact us to purchase this display.
AM043NBG01
4.3″ Resistive Touch TFT Display
Features:
- IPS TFT
- 480 x 272 pixels
- Sunlight readable
- All viewing angle
- 24-bit RGB interface
- 3.3V LCD
Controller/Driver:
SC7283
Documentation:
Purchase:
Please contact us to purchase this display.
AM043NVG01
4.3″ Capacitive Touch TFT Display
Features:
- IPS TFT
- 480 x 272 pixels
- Sunlight readable
- All viewing angle
- 24-bit RGB interface
- 3.3V LCD
Controller/Driver:
SC7283
FT5436
Documentation:
Purchase
Please contact us to purchase this display.
AM070RDG01
7″ TFT Dispay
Features:
- IPS TFT
- 800 x 480 pixels
- Sunlight readable
- Few viewing angle
- 24-bit RGB interface
- 3V LCD
Purchase
Please contact us to purchase this display.
AM070RBG01
7″ Resistive Touch TFT Display
Features:
- IPS TFT
- 800 x 480 pixels
- Sunlight readable
- Few viewing angle
- 24-bit RGB interface
- 3V LCD
Purchase
Please contact us to purchase this display.
AM070RVG01
7″ Capacitive Touch TFT Dispay
Features:
- IPS TFT
- 800 x 480 pixels
- Sunlight readable
- Few viewing angle
- 24-bit RGB interface
- 3V LCD
Purchase
Please contact us to purchase this display.
FAQs
Q: What is the main difference between a Simple Display and an Interactive Digital Display Module?
A: A Simple Display is a “target” device—it has no onboard computing and requires an application-class processor with a GUI framework to drive every pixel and manage the constant 60 Hz refresh rate.
Q: What interfaces do your Simple Displays support?
A: Our panels support standard high-bandwidth digital video interfaces, including 24-bit RGB-TTL, LVDS, and MIPI, depending on the specific display selected.
Q: Can I use GEMstudio™ Pro with a Simple Display?
A: No. GEMstudio™ is specifically designed to work with the application processor and software framework integrated into our Interactive Digital Display Modules to offload the host.
